KBA127-I8T2 2 million infrared 100 meters coaxial analog dual-purpose mine explosion-proof camera

KBA127-I8T2 2 million infrared 100 meters coaxial analog dual-purpose mine explosion-proof camera

Application scenarios:
The equipment has obtained the highest certification of Class II explosion-proof level and the temperature ( T ) the highest level of certification, suitable for A , II B , II C surroundings, T1 ~ T6 Group of explosive mixtures of explosive and flammable gases and air 0 Area, 1 Area, 2 Areas and places where explosive and flammable dust is mixed with air 20 Area, 21 Area, 22 Explosion Hazardous Locations , Such as coal mine methane gas, explosive gas, dust environment. Such as: refining, oil production, gas production, chemical industry, fireworks production, food processing and storage, gas stations and other environments.

Features:
· Mine safety sign number: MFA190043
· Explosion-proof mark: Ex d I Mb
· Protection class: IP68
· Product Standards: GB3836-2010,MT 209-1990,Q/BL927001-2018
· Stainless steel material design, double explosion-proof certification
· Wide voltage design supports user-customized AC and DC POE Power supply
· The window glass is precisely processed, with self-cleaning function, and can be used in a hydrofluoric acid environment

contact us
  • KBA127-I8T2 2 million infrared 100 meters coaxial analog dual-purpose mine explosion-proof camera
  • KBA127-I8T2 2 million infrared 100 meters coaxial analog dual-purpose mine explosion-proof camera
  • KBA127-I8T2 2 million infrared 100 meters coaxial analog dual-purpose mine explosion-proof camera

model

KBA127-IT82

name

4 combine 1 Fully compatible 200 10,000 infrared waterproof mine explosion-proof camera

sensor type

2.0 Mega Progressive Scan CMOS

total pixels

1930( Level ) × 1088( vertical )

Minimum illumination

0.1Lux @ (F1.2,AGC ON),0Lux with IR

shutter

1/25 seconds to 1/50,000 second

lens

3.6mm(6mm,8mm,12mm,16mm optional )

lens type

M12

Day and night switching mode

ICR Infrared filter type

Synchronously

Intrasync

frame rate

1080p@25fps

HD video output

1 road BNC(TVI/AHD/CVI/CVBS ) can switch the output , meets the HDTVI standard

signal to noise ratio

more than the 62dB

Camera identification number

open / close ( designation number 0-255)

auto gain

support

color / black and white

automatic / color / black and white

white balance

automatic / manual /PUSH/8000K/6000K/4200K/3200K/ Keep

BLC

support

language

Chinese / English

Function settings

mirroring (horizontal, vertical, center) etc.

Operating temperature and humidity

-40 °C ~60 °C , Humidity is less than 90%( no condensation )

power supply

DC12V ± 15% /AC127V

Power consumption

4W MAX

Protection class

IP68

communication

Coaxial video control

Coaxial output control protocol: HIKVISION-C

Infrared irradiation distance

100m

weight

12kg

Image related:

• Adopt 200 progressive scan CMOS, Capture moving images without aliasing

• Support coaxial HD output , Clear and detailed images , Resolution up to 1080p

• low light , 0.1Lux @ (F1.2,AGC ON), 0Lux with IR

• support ICR Infrared filter type automatic switching , Automatic color to black function , Realize day and night monitoring

• support OSD menu control , Suitable for user-defined settings

• support 2D digital noise reduction , Ensure that the picture is clean and delicate in a variety of environments

• Support intelligence SMART IR Function , Effectively prevent the problem of near infrared overexposure

• meets the IP68 Grade waterproof design , High reliability

• Support coaxial video control (HIKVISION-C protocol ) Function

• TVI/AHD/CVI/CVBS The output can be switched at will according to the back-end device type

Accessories:

Mine explosion-proof camera wall mount bracket BL-EX55LA

Mine explosion-proof camera universal joint BL-EX10ZA

Mine explosion-proof camera junction box 400X300X200

Ordering Information:

KBA127-I8T2 ( 4mm) Coal mine underground mine explosion-proof camera

KBA127-I8T2 ( 6mm) Coal mine underground mine explosion-proof camera

KBA127-I8T2 ( 8mm) Coal mine underground mine explosion-proof camera

KBA127-I8T2 ( 12mm) Coal mine underground mine explosion-proof camera

KBA127-I8T2F ( 4mm) Coal mine underground fiber optic mining explosion-proof camera

KBA127-I8T2F ( 6mm) Coal mine underground fiber optic mining explosion-proof camera

KBA127-I8T2F ( 8mm) Coal mine underground fiber optic mining explosion-proof camera

KBA127-I8T2F ( 12mm) Coal mine underground fiber optic mining explosion-proof camera
