Home / Product / Analog camera / Explosion-proof bolt / 2 million / BL-EX320P-I5(4/6/8/12mm) 2 million infrared 50 meters 4 in 1 output analog explosion-proof camera
Application scenarios:
The equipment has obtained the highest certification of Class II explosion-proof level and the temperature ( T ) the highest level of certification, suitable for A , II B , II C surroundings, T1 ~ T6 Group of explosive mixtures of explosive and flammable gases and air 0 Area, 1 Area, 2 Areas and places where explosive and flammable dust is mixed with air 20 Area, 21 Area, 22 In addition to coal mine methane gas, other explosive gas and dust environments in the area with explosion hazard. Such as: refining, oil production, gas production, chemical industry, fireworks production, food processing and storage, gas stations and other environments.
Features:
· Explosion-proof mark: Exd IIC T6 Gb /ExtD A21 IP68 T80 °C
· Protection class: IP68
· Product Standards: Q/006-2016
· Stainless steel material design, double explosion-proof certification
· Wide voltage design supports user-customized AC and DC POE Power supply
· The window glass is precisely processed, with self-cleaning function, and can be used in a hydrofluoric acid environment
model | BL-EX320P-I5 |
name | 4 combine 1 Fully compatible 200 10,000 Infrared Waterproof Gun Type Explosion-Proof Camera |
sensor type | 2.0 Mega Progressive Scan CMOS |
total pixels | 1930( Level ) × 1088( vertical ) |
Minimum illumination | 0.1Lux @ (F1.2,AGC ON),0Lux with IR |
shutter | 1/25 seconds to 1/50,000 second |
lens | 3.6mm(6mm,8mm,12mm,16mm optional ) |
lens type | M12 |
Day and night switching mode | ICR Infrared filter type |
Synchronously | Intrasync |
frame rate | 1080p@25fps |
HD video output | 1 road BNC(TVI/AHD/CVI/CVBS ) can switch the output , meets the HDTVI standard |
signal to noise ratio | more than the 62dB |
Camera identification number | open / close ( designation number 0-255) |
auto gain | support |
color / black and white | automatic / color / black and white |
white balance | automatic / manual /PUSH/8000K/6000K/4200K/3200K/ Keep |
BLC | support |
language | Chinese / English |
Function settings | mirroring (horizontal, vertical, center) etc. |
Operating temperature and humidity | -40 °C ~60 °C , Humidity is less than 90%( no condensation ) |
power supply | DC12V ± 15% |
Power consumption | 4W MAX |
Protection class | IP68 |
communication | Coaxial video control |
Coaxial output control protocol: HIKVISION-C | |
Infrared irradiation distance | M/I3 ( 30 Meter), I5(50 Meter), I8 ( 80 Meter) |
weight | 5kg |
Image related:
• Adopt 200 progressive scan CMOS, Capture moving images without aliasing
• Support coaxial HD output , Clear and detailed images , Resolution up to 1080p
• low light , 0.1Lux @ (F1.2,AGC ON), 0Lux with IR
• support ICR Infrared filter type automatic switching , Automatic color to black function , Realize day and night monitoring
• support OSD menu control , Suitable for user-defined settings
• support 2D digital noise reduction , Ensure that the picture is clean and delicate in a variety of environments
• Support intelligence SMART IR Function , Effectively prevent the problem of near infrared overexposure
• meets the IP68 Grade waterproof design , High reliability
• Support coaxial video control (HIKVISION-C protocol ) Function
• TVI/AHD/CVI/CVBS The output can be switched at will according to the back-end device type
Accessories:
Explosion Proof Camera Wall Mount Bracket BL-EX40LA
Explosion-proof camera hoisting bracket BL-EX40IA
Explosion-proof camera junction box 200X150X100
Explosion-proof camera hose BL-EX100P
Ordering Information:
304 Stainless steel 200 Wan infrared 50 Meter 4 combine 1 Analog explosion proof camera BL-EX320P-I5
316L Stainless steel 200 Wan infrared 50 Meter 4 combine 1 Analog explosion proof camera BL-EX320P-I5/316L
