Home / Product / Web video camera / Explosion Proof Dome Camera / 2 million / BL-EX3204H6-I8Z(2.8-12mm) ) 2 million super starlight infrared 100 meters 4x electric zoom explosion-proof network camera
Application scenarios:
The equipment has obtained the highest certification of Class II explosion-proof level and the highest certification of temperature (T) level. It is suitable for Zone 0, Zone 1, Zone 2 with IIA, IIB, IIC environment, and explosive mixtures formed by explosive and flammable gases and air in groups T1~T6. Zone 20, Zone 21 and Zone 22 where explosive and flammable dust is mixed with air, except for coal mine methane gas, other explosive gas and dust environments. Such as: refining, oil production, gas production, chemical industry, fireworks production, food processing and storage, gas stations and other environments.
Features:
· Explosion proof mark: Exd IIC T6 Gb /ExtD A21 IP68 T80℃
· Protection class: IP68
· Product standard: Q/006-2016
· Stainless steel material design, double explosion-proof certification
· Wide voltage design supports user-customized AC/DC POE power supply mode
· The window glass is precisely processed, with self-cleaning function, and can be used in a hydrofluoric acid environment
sensor type | 1/1.8" Progressive Scan CMOS |
digital noise reduction | 3D digital noise reduction |
Minimum illumination | Color: 0.0005 Lux @ (F1.2, AGC ON); B&W: 0.0001 Lux @ (F1.2, AGC ON); 0 Lux with IR |
slow shutter | support |
lens | 2.8-12mm F1.4, horizontal field of view 90.1°~31°8-32mm F1.4, horizontal field of view 42.2°~13.5° |
Wide dynamic range | 120dB |
shutter | 1 second to 1/100,000 second |
Day and night switching mode | ICR infrared filter type |
video compression standard | H.265/H.264/MJPEG |
H.265 encoding type | Main Profile |
H.264 encoding type | BaseLine Profile / Main Profile / High Profile |
Video compression bit rate | 32Kbps~16Mbps |
audio compression standard | G.711/G.722.1/G.726/MP2L2/AAC/PCM |
Audio compression bit rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-192Kbps(MP2L2) / 16-64Kbps(AAC) |
Day and night conversion method | Automatic, timing, alarm trigger |
maximum image size | 1920×1080 |
Main stream resolution and frame rate | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720); 60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
region clipping | Support cropped screen transmission |
Resolution and frame rate of the third stream | Independent of the main stream setting, maximum support: 50Hz: 25fps (1920 × 1080); 60Hz: 30fps (1920 × 1080) |
Image settings | Corridor Mode, Saturation, Brightness, Contrast, Sharpness can be adjusted by client or browser |
BLC | support, selectable area |
Electronic image stabilization | support |
through fog | support |
image overlay | Support BMP 24-bit image overlay, selectable area |
area of interest | ROI supports three code streams to set 4 fixed areas respectively to ensure face details under low code rate |
Behavior analysis | Border crossing detection, area intrusion detection, entering/exiting area detection, loitering detection, people gathering detection, fast motion detection, parking detection, item left/taken detection |
Anomaly detection | Scene change detection, audio steep rise/fall detection, audio presence or absence detection, virtual focus detection |
Identification detection | face detection |
Interface Protocol | ONVIF (PROFILE S, PROFILE G), ISAPI, GB28181 |
Smart alarm | Motion detection, occlusion alarm, network cable disconnection, IP address conflict, memory full, memory error |
General function | One-key recovery, anti-flicker, three-stream, heartbeat, mirroring, password protection, video masking, watermark technology, IP address filtering |
supporting agreement | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
Storage function | Support Micro SD/Micro SDHC/Micro SDXC card (128G) disconnected network local storage and disconnected network resume, NAS (NFS, SMB/CIFS are supported) |
Communication Interface | 1 RJ45 10M / 100M / 1000M adaptive Ethernet port |
video output | 1Vp-p Composite Output(75Ω/BNC) |
audio port | 1 pair of audio input (Line in)/output interface |
Communication Interface | 1 RS485 interface |
Alarm input | 1 way |
Alarm Output | 1 channel (alarm output maximum supports AC/DC 24V 1A Max) |
Power interface type | Two-wire power interface |
Operating temperature and humidity | -30℃~60℃, humidity less than 95% (no condensation); -H:-40℃~60℃ |
power supply | DC12V±15% / PoE(802.3at) |
Power consumption | 12W MAX |
Protection class | IP68 |
weight | 6kg |
Infrared irradiation distance | 100 metres |
* | *Recommended to configure two-wire power supply |
Features
Smart function
Smart detection: 10 behavior analysis, 4 abnormal detection, 1 identification detection
Smart Recording: Supports the function of continuous transmission after disconnection to ensure that the recording is not lost, and cooperates with Smart NVR/SD card to realize intelligent post-retrieval, analysis and concentrated playback of event recordings
Smart coding: support low bit rate, low latency, ROI enhanced coding, SVC adaptive coding technology, support smart265 coding
Image correlation
The highest resolution can reach 2 million pixels (1920×1080), and the maximum output Full HD 1920×1080@30fps real-time image
Support rotation mode, increase the monitoring area in the longitudinal and narrow environment
Support backlight compensation, automatic electronic shutter function, automatic aperture, slow shutter, adapt to different monitoring environments
Support area cropping, small bandwidth to see big details
Stream smoothing settings, adapt to different requirements for image quality and fluency in different scenarios
Support GBK font library, support more Chinese characters and uncommon characters overlay, support OSD color selection
Supports fog penetration, electronic image stabilization and has a variety of white balance modes, suitable for various scene needs
Support wide dynamic range up to 120dB, suitable for backlight environment monitoring, support 3D digital noise reduction function
Infrared function
Using high-efficiency infrared array lights, low power consumption, the illumination distance is up to 50m (2.8-12mm)
Infrared anti-reflection panel, improve infrared light transmittance
Smart IR function, intelligently change the brightness of the infrared light according to the focal length of the lens, so that the infrared supplementary light is uniform, the close objects are not exposed, and the distant objects are not missed
System functions
Support ONVIF (profile S/profile G), ISAPI, EZVIZ cloud, GB28181 and E home protocol access
Support three-stream technology, dual-channel high-definition, support simultaneous 20-channel streaming
Anti-stray light glass is used to ensure the effect of the picture and eliminate the interference of stray light
Support lightning protection, anti-surge, anti-static
Optional intelligent temperature control, low power heating, support low temperature start (-H optional)
Anti-stray light glass is used to ensure the effect of the picture and eliminate the interference of stray light
Full-featured: image overlay, IP address filtering, heartbeat, mirroring, alarm, one-key recovery, etc.
Interface function
Support standard 128G Micro SD/Micro SDHC/Micro SDXC card storage
Support 10M / 100M /1000M adaptive network port
Supports 1 pair of audio input/output (-S)
Support 1 channel alarm input (-S)
Support 1 channel alarm output (-S)
Support BNC analog output
Security service
Support three-level user rights management, support authorized users and passwords, support IP address filtering,
Support HTTPS security authentication, support to create certificates
Change the password when the initial device is powered on to ensure password security
Support user login locking mechanism
Support IP68 protection level
Accessories:
Explosion-proof camera wall mount BL-EX40LA
Explosion-proof camera hoisting bracket BL-EX40IA
Explosion-proof camera junction box BL-EXC200A
Explosion-proof camera hose BL-EX100P
Ordering Information:
304 stainless steel 2 million 4 times super starlight explosion-proof network camera BL-EX3204H6-I8Z
316L stainless steel 2 million 4 times super starlight explosion-proof network camera BL-EX3204H6-I8Z/316L
