| sensor type | 1/2.7" Progressive Scan CMOS |
| Minimum illumination | Color: 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| lens | 7~35 mm, horizontal field of view: 31° ~ |
| | 10° optional) |
| Adjust the angle | Horizontal: 0° ~355°; Vertical: 0° ~ 75°; Rotation: 0° ~355° |
| Wide dynamic range | 120dB |
| shutter | 1/3 s ~ 1/100,000 s |
| Day and night switching mode | ICR infrared filter type |
| SVC encoding | H.264, H.265 support |
| video compression standard | Main stream: H.265/H.264 |
| | Substream: H.265/H.264/MJPEG |
| H.265 encoding type | Main Profile |
| H.264 encoding type | BaseLine Profile/Main Profile/High Profile |
| Video compression bit rate | 32 Kbps ~ 8 Mbps |
| audio compression standard | G.711/G.722.1/G.726/MP2L2/PCM/AAC |
| Audio compression bit rate | 64 Kbps(G.711)/16 Kbps(G.722.1)/16 Kbps(G.726)/32-192 Kbps(MP2L2)/16-64 |
| | Kbps(AAC) |
| maximum image size | 1920 × 1080 |
| image enhancement | Backlight compensation, strong light suppression, 3D digital noise reduction |
| frame rate | Main stream: 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| | Substream: 50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240) |
| Image settings | Saturation, Brightness, Contrast, Sharpness, White Balance adjustable through client or browser |
| area of interest | Support main stream, set 1 fixed area for sub stream |
| supporting agreement | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, |
| | PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, |
| | SSL/TLS |
| Interface Protocol | ONVIF(PROFILE S, PROFILE G), ISAPI, SDK, GB28181 |
| General function | Mirroring, Password Protection, Video Masking, Watermarking Technology, IP Address Filtering |
| Storage function | Support Micro SD/Micro SDHC/Micro SDXC card (128 GB or 256 GB) disconnected network local storage and disconnection |
| | Network resume, NAS (NFS, SMB/CIFS are supported), with Hikvision black card to support SD card encryption and SD card status |
| | detect |
| Factory reset | Support RESET button, client or browser recovery |
| Anomaly detection | Motion detection, occlusion alarm, network cable disconnection, IP address conflict, illegal login, memory full, memory error |
| Smart detection | Out-of-bounds detection, area intrusion detection, entering area detection, leaving area detection, support sound alarm output |
| face capture | Detect, track, capture, score, filter, and output the best face capture for moving faces |
| face capture mode | best shot, quick shot |
| audio port | Built-in 1-way speaker and 1-way microphone |
| | 1 channel audio input (Line in), 1 channel audio output (Line out) |
| Alarm interface | 1 alarm input, 1 alarm output (relay output supports AC24 V/DC24 V, 1 A) |
| Communication Interface | 1 RJ45 10 M/100 M adaptive Ethernet port |
| Protection class | IP68 |
| power supply | DC12 V ± 20%/PoE(802.3af), "without P model" does not support PoE |
| Operating temperature and humidity | -30 ℃ ~ 60 ℃, humidity less than 95% (non-condensing) |
| Power consumption | DC12V: 11W Max |
| | PoE: Max: 12.9 W Max |
| weight | 5kg |
| The furthest fill light distance | 30 m |
| Power Output | DC12 V 100 mA, |
| Riot class | IK10 |
