Home / Product / Special product / Mine camera / 2MP / KBA127-B64-I8Z ) 2 million pixel 100 meters infrared 4x electric zoom network explosion-proof camera
Application scenarios:
equipment acquisition II Class explosion-proof level highest certification and temperature ( T ) at the highest level of certification, for those with IIA , IIB , IIC surroundings, T1 ~ T6 Group of explosive mixtures of explosive and flammable gases and air 0 Area, 1 Area, 2 Areas and places where explosive and flammable dust is mixed with air 20 Area, 21 Area, 22 Explosion hazard place in the area, coal mine methane gas, other explosive gas, dust environment. Such as: refining, oil production, gas production, chemical industry, fireworks production, food processing and storage, gas stations and other environments.
Features:
· Mine safety sign number: MFA190043
· Explosion-proof mark: Ex d I Mb
· Protection class: IP68
· Product Standards: Q/006-2016
· Stainless steel material design, double explosion-proof certification
· Wide voltage design supports user-customized AC and DC POE Power supply
· The window glass is precisely processed, with self-cleaning function, and can be used in a hydrofluoric acid environment
model | KBA127-B64-I8Z |
name | 200 Ten thousand 1/2.8" CMOS ICR Day and night barrel network camera |
sensor type | 1/2.8" Progressive Scan CMOS |
shutter | 1 seconds to 1/100,000 second |
Auto iris | DC drive |
Day and night switching mode | ICR Infrared filter type |
Wide dynamic range | digital wide dynamic |
BLC | Yes, selectable region |
digital noise reduction | 3D digital noise reduction |
slow shutter | support |
video compression standard | H.264/MJPEG |
Compressed output bit rate | 32Kbps~8Mbps |
Audio compression bit rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
maximum image size | 1920 × 1080 |
frame rate | 50Hz: 25fps (1920 × 1080,1280 × 960,1280 × 720) ; |
60Hz: 30fps (1920 × 1080,1280 × 960,1280 × 720) | |
Resolution and frame rate of the third stream | Independent of the main stream settings, supports up to: |
50Hz: 1fps(1920 × 1080) | |
60Hz: 1fps(1920 × 1080) | |
Image settings | corridor mode , saturation , brightness , Contrast , Sharpness adjustable via client or browser |
corridor mode | support |
BLC | support , selectable area |
through fog | support |
image overlay | support BMP 24 bitmap overlay , selectable area |
Day and night conversion method | automatic , timing , Alarm trigger |
area of interest | ROI Support dual stream settings separately 4 fixed area or dynamic tracking |
Storage function | support Micro SD/SDHC/SDXC Card (128G) Disconnected local storage ,NAS(NFS,SMB/CIFS Both support ) |
Interface Protocol | ONVIF,PSIA,CGI,ISAPI,GB28181 |
Smart alarm | Scene Change Detection , Area Intrusion Detection , Audio Anomaly Detection , virtual focus detection , Motion Detection , face detection , Dynamic Analysis , Occlusion alarm , The network cable is broken ,IP address conflict , memory full , memory error |
supporting agreement | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, |
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour | |
General function | One-click recovery , Anti-flicker , three stream , heartbeat , mirror , password protection , video cover , watermarking technology , |
anonymous access ,IP address filtering | |
Communication Interface | 1 indivual RJ45 10M / 100M Adaptive Ethernet port |
Ambient noise filtering | support |
Operating temperature and humidity | -30 °C ~60 °C , Humidity is less than 95%( no condensation ) ; |
power supply | DC12V / PoE(802.3at) |
Power consumption | 20.7W MAX |
Protection class | IP68 |
size( mm ) | See drawing |
weight | 10kg |
Remark | * " -S ” means having 1 right 3.5mm audio input (Line in)/ Output Interface, 1 indivual BNC analog output, 1 input for alarm / Output Interface ( Alarm output maximum support DC24V 1A or AC110V 500mA) |
* Two-wire power supply is recommended | |
Infrared irradiation distance | 100 m |
Main features
· use H.264 coding , Highest resolution up to 200 CMOS( 1920×1080 ) , Maximum output Full HD 1080p@30fps live image
· line-by-line scan CMOS, Capture moving images without aliasing
· use ROI , SVC video compression technology , High compression ratio , and very flexible , Ultra low bit rate
· Stream smoothing settings, adapt to different requirements for image quality and fluency in different scenarios
· support GBK Font library, support more Chinese characters and uncommon characters superimposed
· support OSD Color optional
· Support digital wide dynamic , support 3D digital noise reduction
· Adopt high-efficiency infrared lamp , long lasting , Irradiation distance up to 20-50 Meter (8-32mm Lens reachable 30-100 Meter ) ;support smart IR , to prevent infrared overexposure at night
· Support defogging to prevent fogging inside the device
· Anti-stray light glass is used to ensure the effect of the picture and eliminate the interference of stray light
· support max 128G Micro SD/SDHC/SDXC Card local storage
· ICR Infrared filter type automatic switching , Realize true day and night monitoring
· Supports simultaneous output of three streams , Support mobile phone monitoring
· support fog , And has a variety of white balance modes , Suitable for various scenarios
· Backlight compensation supported , Automatic electronic shutter function , Auto iris , slow shutter , corridor mode , Adapt to different monitoring environments
· With out-of-bounds detection , Scene Change Detection , Area Intrusion Detection , Audio Anomaly Detection , virtual focus detection , Motion Detection , face detection , Dynamic analysis and other alarm functions
· Support intelligent post-retrieval, cooperate with NVR Secondary retrieval analysis of support events
· full functioning : image overlay , anonymous access ,IP address filtering , heartbeat , mirror ,PTZ control , Call the police , One-click recovery, etc.
· support GB28181 protocol, support EHOME Platform access
· support NAS , Email , FTP , NTP server test
· support HTTPS,SSH and other security authentication, support the creation of certificates
· Change the password when the initial device is powered on to ensure password security
· Support user login locking mechanism, and password complexity prompt
· meets the IP68 Grade dustproof and waterproof design , High reliability
Application scenarios
Applicable to mines, tunnels, energy, chemicals, petroleum, petrochemicals, gas stations, electricity, steel, construction sites, school laboratories, fireworks, firecrackers, ships, special vehicles , , piers, islands, etc.
Accessories:
Mine explosion-proof camera wall mount bracket BL-EX55LA
Mine explosion-proof camera universal joint BL-EX10ZA
Mine explosion-proof camera junction box BL-EXC400A
Ordering Information:
200 Wan infrared 100 Meter 2.8-12mm Electric zoom coal mine underground explosion-proof camera KBA127-B64-I8Z
200 Wan infrared 100 Meter 2.8-12mm Electric zoom 100M fiber optic coal mine underground explosion-proof camera KBA127-B64-I8ZF
