Home / Product / Web video camera / Explosion Proof Dome Camera / 3000000 / BL-EX435(P)IM-A180(1.16mm) 3 million fisheye panoramic fixed focus infrared explosion-proof network dome camera
Application scenarios:
The equipment has obtained the highest certification of Class II explosion-proof level and the highest certification of temperature (T) level. It is suitable for Zone 0, Zone 1, Zone 2 with IIA, IIB, IIC environment, and explosive mixtures formed by explosive and flammable gases and air in groups T1~T6. Zone 20, Zone 21 and Zone 22 where explosive and flammable dust is mixed with air, except for coal mine methane gas, other explosive gas and dust environments. Such as: refining, oil production, gas production, chemical industry, fireworks production, food processing and storage, gas stations and other environments.
Features:
· Explosion proof mark: Exd IIC T6 Gb /ExtD A21 IP68 T80℃
· Protection class: IP68
· Product standard: Q/006-2016
· Stainless steel material design, double explosion-proof certification
· Wide voltage design supports user-customized AC/DC POE power supply mode
· The window glass is precisely processed, with self-cleaning function, and can be used in a hydrofluoric acid environment
model | BL-EX435(P)IM-A180 |
name | 3 million CMOS ICR panoramic day and night network camera |
maximum image size | 2048x1536 |
Picture correction | Support 180°, 360°, PTZ multiple expansion and combination modes, need client or browser control to achieve |
ePTZ | Support preset point and cruise path setting |
lens | 1.16mm, F2.2; Horizontal field of view: 180° Vertical field of view: 180° |
sensor type | 1/2.8" Progressive Scan CMOS |
shutter | 1/3 second to 1/100,000 second |
Day and night switching mode | ICR infrared filter type |
Wide dynamic range | 120dB |
BLC | Yes, selectable region |
digital noise reduction | 3D digital noise reduction |
Minimum illumination | Color: 0.005Lux @(F1.2,AGCON); 0 LUX with IR |
video compression standard | Smart 265/H.265/H.264/MJPEG |
H.264 encoding type | Baseline Profile / Main Profile |
Compressed output bit rate | 32Kbps~16Mbps |
audio compression standard | G.711/G.722.1/G.726/MP2L2 /AAC |
Audio compression bit rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
Main stream resolution and frame rate | 50Hz: 25fps (2048 x 1536, 1600×1200, 1280 x 960) |
| 60Hz: 30fps (2048 x 1536, 1600×1200, 1280 x 960) |
Storage function | Support Micro SD/SDHC/SDXC card (128G) off-network local storage, NAS (NFS, SMB/CIFS are supported) |
Interface Protocol | ONVIF(PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
Smart alarm | Cross-border detection, regional intrusion detection, motion detection, occlusion alarm, network cable disconnection, IP address conflict, memory full, memory error |
General function | One-key recovery, anti-flicker, dual stream, heartbeat, mirroring, password protection, video masking, watermark technology, anonymous access, IP address filtering |
supporting agreement | TCP/IP,UDP,ARP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, |
| PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
Communication Interface | 1 RJ45 10M / 100M adaptive Ethernet port |
wireless standard | IEEE802.11b, 802.11g, 802.11n |
Frequency Range | 2.4 GHz ~ 2.4835 GHz |
Safety | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Transmission rate | 11b: 11Mbps 11g: 54Mbps 11n: Up to 150Mbps |
Transmission distance | 50 meters (no blocking and no interference, varies according to the environment) |
Operating temperature and humidity | -10℃~40℃, humidity less than 95% (no condensation) |
power supply | DC12V±25%/ / PoE(802.3af), (model without P, does not support POE) |
Power consumption | 6.4W MAX |
Infrared irradiation distance | Up to 10 meters |
weight | 4kg |
* | *A separate DC12V Φ5.5mm round head power supply is required |
| *"-S" means it has 1 pair of audio input (Line in)/output interface (plug-in type), 1 pair of alarm input/output (transistor: more than 30 mA, it is recommended to add relay) interface |
Image correlation
3 million pixel progressive scan CMOS, maximum output 2048 x 1536@30fps image, at this resolution a live image can be output
Using ROI, SVC and other video compression technologies, the compression ratio is high, and the processing is very flexible, ultra-low latency, ultra-low bit rate, and supports smart265 encoding
Support GBK font library, support more Chinese characters and uncommon characters superimposed
Optional high-efficiency infrared lamp, long service life, the irradiation distance can reach 10 meters
Support smart IR to prevent infrared overexposure at night
Support independent configuration of two sets of parameters day and night
Support 120dB ultra-wide dynamic, support 3D digital noise reduction function
Supports up to 128G Micro SD/SDHC/SDXC card local storage
ICR infrared filter type automatic switching to achieve real day and night monitoring
Support three installation methods of ceiling, wall and desktop, support web and client fisheye correction
Support mobile phone monitoring
With a variety of white balance modes, suitable for various scene needs
Support backlight compensation, automatic electronic shutter function, adapt to different monitoring environments
Full-featured: IP address filtering, heartbeat, PTZ control, alarm, one-key recovery, etc.
Intelligent alarm: cross-border detection, regional intrusion detection
Support NAS, Email, FTP, NTP server test
Support HTTPS security authentication, support for creating certificates
Change the password when the initial device is powered on to ensure password security
Support user login locking mechanism, and password complexity prompt
Accessories:
Explosion-proof hemisphere wall bracket BL-EX20LB(M)
Explosion-proof hemisphere hoisting bracket BL-EX40IA(M)
Explosion-proof camera junction box BL-EXC200A
Explosion-proof camera hose BL-EX100P
Ordering Information:
304 stainless steel 3 million fisheye panoramic infrared explosion-proof network dome camera BL-EX435IM-A180
304 stainless steel 3 million Poe fisheye panoramic infrared explosion-proof network dome camera BL-EX435PIM-A180
316L stainless steel 3 million fisheye panoramic infrared explosion-proof network dome camera BL-EX435IM-A180/316L
316L stainless steel 3 million Poe fisheye panoramic infrared explosion-proof network dome camera BL-EX435PIM-A180/316L
