Home / Product / Web video camera / Explosion-proof dome camera / 3000000 / BL-EX7320W-A 3 million 7 inch 20 times explosion-proof integrated dome camera
Application scenarios:
The equipment has obtained the highest certification of Class II explosion-proof level and the temperature ( T ) the highest level of certification, suitable for A , II B , II C surroundings, T1 ~ T6 Group of explosive mixtures of explosive and flammable gases and air 0 Area, 1 Area, 2 Areas and places where explosive and flammable dust is mixed with air 20 Area, 21 Area, 22 In addition to coal mine methane gas, other explosive gas and dust environments in the area with explosive risk. Such as: refining, oil production, gas production, chemical industry, fireworks production, food processing and storage, gas stations and other environments.
Features:
· Explosion-proof mark: Exd IIC T6 Gb /ExtD A21 IP68 T80 °C
· Protection class: IP68
· Product Standards: Q/006-2016
· Stainless steel material design, double explosion-proof certification
· Wide voltage design supports user-customized AC and DC POE Power supply
· The window glass is precisely processed, with self-cleaning function, and can be used in a hydrofluoric acid environment
Image Sensor | 1/2.8 " Progressive Scan CMOS |
Minimum illumination | color: 0.05Lux @ (F1.6 , AGC ON) ; black and white: 0.01Lux @(F1.6 , AGC ON) |
Resolution and Frame Rate | main stream |
50Hz: 25fps (2048×1536, 1920×1080, 1280×960, 1280×720), 50fps (1280×960, 1280×720); | |
60Hz: 30fps (2048×1536, 1920×1080, 1280×960, 1280×720), 60fps (1280×960, 1280×720) | |
substream | |
50Hz: 25fps (704×576, 640×480, 352×288); | |
60Hz: 30fps (704×480, 640×480, 352×240) | |
third stream | |
50Hz: 25fps(1920×1080,1280×960,1280×720,704×576,640×480,352×288); | |
60Hz: 30fps (1920×1080, 1280×960, 1280×720, 704×480, 640×480, 352×240) | |
video compression | H.265/H.264/MJPEG |
audio compression | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC/PCM |
white balance | automatic / manual / Auto tracking white balance / outdoor / indoor / Fluorescent white balance / Sodium White Balance |
Gain control | automatic / manual |
signal to noise ratio | more than the 52dB |
3D digital noise reduction | support |
BLC | support |
area exposure / focus | support |
electronic shutter | 1/1-1/30,000s |
Day and night mode | automatic ICR color to black |
digital zoom | 16 times |
privacy mask | most 8 block area |
focus mode | automatic / semi-automatic / manual |
focal length | 4.7-94mm, 20 Times Optical |
Zoom speed | About 2.7 second ( optics , wide angle - look far ) |
Horizontal viewing angle | 58.3-3.2 Spend ( wide angle - look far ) |
close-up | 10-1500mm( wide angle - look far ) |
Aperture number | F1.6-F3.5 |
Smart detect | Regional intrusion detection, out-of-bounds detection, audio anomaly detection, motion detection, video occlusion detection |
Smart video | Resume upload after disconnection, intelligent post-retrieval |
Smart image enhancement | 120dB Ultra-wide dynamic, through fog, strong light suppression, electronic image stabilization, Smart IR |
Smart coding | smart265 , smart264 , low bit rate, ROI |
Device Anomaly Detection | network cable disconnection, IP Address conflict, memory full, memory error, illegal access |
Horizontal and vertical range | Level 360° ;vertical -5°-90°( Auto flip ) |
horizontal speed | Horizontal keying speed: 0.1°-250°/s, Speed can be set; horizontal preset speed: 300°/s |
vertical speed | Vertical keying speed: 0.1°-150°/s, Speed can be set ; Vertical preset speed: 200°/s |
3D position | support |
Scale zoom | support |
Number of preset points | 300 indivual |
cruise scan | 8 strips, each can be added 32 preset points |
pattern scan | 4 , the record time of each path is greater than 10 minute |
Power-off memory | support |
Azimuth information display | open / close |
Preset video freeze | support |
watch function | Preset / pattern scan / cruise scan / auto scan / vertical scan / random scan / frame scan / Panoramic scan |
timed task | Preset / pattern scan / cruise scan / auto scan / vertical scan / random scan / frame scan / Panoramic scan / Dome restart / Dome calibration |
Network protocol | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, |
DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour | |
application programming interface | Open to support software integration API , supports standard protocols (ONVIF , PSIA , CGI) , support Hikvision SDK Access and support with third-party management platforms GB/T28181 protocol, support E Home protocol, support EZVIZ cloud access |
browser | support IE7 ,Chrome18 ,Firefox5.0 ,Safari5.02 browser |
Number of simultaneous preview videos | most 20 road |
User rights | most 32 users, 3 class : Administrators, Operators and Regular Users |
safe mode | Authorized username and password, and MAC address binding; HTTPS encryption; IEEE 802.1x network access control, IP address filtering |
Power interface | AC24V( only -A Model support ) ; DC12V( only -D Model support ) |
Network Interface | RJ45 network port, adaptive 10M/100M network data ;support POE (802.3at) power supply (only -E model) |
audio input / output | 1 Audio input, audio peak :2-2.4V[p-p] ,input resistance :1KΩ±10% ; 1 Audio output, line level, impedance :600Ω |
Alarm input / output | 2 Road alarm input; 1 Alarm output; support setting alarm linkage preset point / cruise scan / pattern scan /SD Card video / Alarm Output / mail / Upload Center / upload FTP |
SD card interface | built-in Micro SD card slot, support Micro SD/SDHC/SDXC card (maximum supported 128G ) |
Power consumption | 18W max |
Operating temperature and humidity | -30℃-65℃ (outdoor) /-10℃-50℃ (indoor); humidity less than 90% |
Protection class | IP68( outdoor );TVS 4000V Lightning protection, surge protection, surge protection, meet GB/T17626.5 four standard |
weight | 14kg |
Product Features
support max 2048 × 1536@30fps HD picture output
support H.265 Efficient compression algorithm, which can greatly save storage space
Support ultra-low illumination, 0.05Lux/F1.6( color ),0.01Lux/F1.6( black and white )
support 20 magnification optical zoom, 16 digital zoom
support 960p@60fps , 720p@60fps High frame rate output
Support three-stream technology, each stream can independently configure resolution and frame rate
Support regional intrusion detection, out-of-bounds detection, motion detection and other intelligent detection functions
Support the function of disconnecting and resuming transmission to ensure that the video is not lost. Smart NVR Realize secondary intelligent retrieval, analysis and condensed playback of event recordings
Support wide dynamic, 3D Digital noise reduction, strong light suppression, electronic image stabilization and other functions
support 360 °Horizontal rotation, vertical orientation -5 ° -90 °
support 300 preset positions, 8 bar cruise scan
support 3D Positioning, you can use the mouse to frame the target to achieve rapid positioning and capture of the target
Support timing snapshot and event snapshot function
Support area exposure and area focus functions
Support center mirror function
Support timed tasks, one-key watch, one-key cruise functions
support PoE ( 802.3at ) power supply (only -E model support)
support 1 audio input and 1 audio output
built-in 2 Road alarm input and 1 Road alarm output, support alarm linkage function
support max 128G of Micro SD/SDHC/SDXC card storage
Support Hikvision SDK , ONVIF , CGI , PSIA , GB/T28181 , E Home Protocol and EZVIZ Cloud Access
Lightning protection, anti-surge, anti-surge, outdoor ball reach IP68 Protection class
Accessories:
Explosion-proof ball machine wall bracket BL-EX40PL
Explosion-proof ball machine hoisting bracket BL-EX30PI
Explosion-proof camera junction box BL-EXC200A
Explosion-proof camera hose BL-EX100P
Ordering Information:
304 Stainless steel 130 Ten thousand 20 times 7 inch explosion-proof integrated dome camera BL-EX7120W-A
316L Stainless steel 130 Ten thousand 20 times 7 inch explosion-proof integrated dome camera BL-EX7120W-A/316L
