| Image Sensor | 1/2.8 " Progressive Scan CMOS |
| Minimum illumination | color: 0.05Lux @ (F1.6 , AGC ON) ; black and white: 0.01Lux @(F1.6 , AGC ON) |
| Resolution and Frame Rate | main stream |
| 50Hz: 25fps (2048×1536, 1920×1080, 1280×960, 1280×720), 50fps (1280×960, 1280×720); |
| 60Hz: 30fps (2048×1536, 1920×1080, 1280×960, 1280×720), 60fps (1280×960, 1280×720) |
| substream |
| 50Hz: 25fps (704×576, 640×480, 352×288); |
| 60Hz: 30fps (704×480, 640×480, 352×240) |
| third stream |
| 50Hz: 25fps(1920×1080,1280×960,1280×720,704×576,640×480,352×288); |
| 60Hz: 30fps (1920×1080, 1280×960, 1280×720, 704×480, 640×480, 352×240) |
| video compression | H.265/H.264/MJPEG |
| audio compression | G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/AAC/PCM |
| white balance | automatic / manual / Auto tracking white balance / outdoor / indoor / Fluorescent white balance / Sodium White Balance |
| Gain control | automatic / manual |
| signal to noise ratio | more than the 52dB |
| 3D digital noise reduction | support |
| BLC | support |
| area exposure / focus | support |
| electronic shutter | 1/1-1/30,000s |
| Day and night mode | automatic ICR color to black |
| digital zoom | 16 times |
| privacy mask | most 8 block area |
| focus mode | automatic / semi-automatic / manual |
| focal length | 4.5-135mm, 30 Times Optical |
| Zoom speed | About 3 second ( optics , wide angle - look far ) |
| Horizontal viewing angle | 58.9-2.11 Spend ( wide angle - look far ) |
| close-up | 10-1500mm( wide angle - look far ) |
| Aperture number | F1.6-F4.4 |
| Smart detect | Regional intrusion detection, out-of-bounds detection, audio anomaly detection, motion detection, video occlusion detection |
| Smart video | Resume upload after disconnection, intelligent post-retrieval |
| Smart image enhancement | Digital wide dynamic, through fog, strong light suppression, electronic image stabilization, Smart IR |
| Smart coding | smart265 , smart264 , low bit rate, ROI |
| Device Anomaly Detection | network cable disconnection, IP Address conflict, memory full, memory error, illegal access |
| Horizontal and vertical range | Level 360° ;vertical -5°-90°( Auto flip ) |
| horizontal speed | Horizontal keying speed: 0.1°-250°/s, Speed can be set; horizontal preset speed: 300°/s |
| vertical speed | Vertical keying speed: 0.1°-150°/s, Speed can be set ; Vertical preset speed: 200°/s |
| 3D position | support |
| Scale zoom | support |
| Number of preset points | 300 indivual |
| cruise scan | 8 strips, each can be added 32 preset points |
| pattern scan | 4 , the record time of each path is greater than 10 minute |
| Power-off memory | support |
| Azimuth information display | open / close |
| Preset video freeze | support |
| watch function | Preset / pattern scan / cruise scan / auto scan / vertical scan / random scan / frame scan / Panoramic scan |
| timed task | Preset / pattern scan / cruise scan / auto scan / vertical scan / random scan / frame scan / Panoramic scan / Dome restart / Dome calibration |
| Network protocol | IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, |
| DNS,DDNS,NTP,RTSP,RTCP,RTP,TCP/IP,UDP,IGMP,ICMP,DHCP,PPPoE,Bonjour |
| application programming interface | Open to support software integration API , supports standard protocols (ONVIF , PSIA , CGI) , support Hikvision SDK Access and support with third-party management platforms GB/T28181 protocol, support E Home protocol, support EZVIZ cloud access |
| browser | support IE7 ,Chrome18 ,Firefox5.0 ,Safari5.02 browser |
| Number of simultaneous preview videos | most 20 road |
| User rights | most 32 users, 3 class : Administrators, Operators and Regular Users |
| safe mode | Authorized username and password, and MAC address binding; HTTPS encryption; IEEE 802.1x network access control, IP address filtering |
| Power interface | AC24V( only -A Model support ) ; DC12V( only -D Model support ) |
| Network Interface | RJ45 network port, adaptive 10M/100M network data ;support POE (802.3at) power supply (only -E model) |
| audio input / output | 1 Audio input, audio peak :2-2.4V[p-p] ,input resistance :1KΩ±10% ; 1 Audio output, line level, impedance :600Ω |
| Alarm input / output | 2 Road alarm input; 1 Alarm output; support setting alarm linkage preset point / cruise scan / pattern scan /SD Card video / Alarm Output / mail / Upload Center / upload FTP |
| SD card interface | built-in Micro SD card slot, support Micro SD/SDHC/SDXC card (maximum supported 128G ) |
| Power consumption | 18W max |
| Operating temperature and humidity | -30℃-65℃ (outdoor) /-10℃-50℃ (indoor); humidity less than 90% |
| Protection class | IP68( outdoor );TVS 4000V Lightning protection, surge protection, surge protection, meet GB/T17626.5 four standard |
| weight | 14kg |
