| model | BL-EX336(P)-I5 |
| name | 3MP 1/2.7" CMOS ICR Starlight IR Array Barrel Network Camera |
| maximum image size | 2304 × 1296 |
| Minimum illumination | 0.005 Lux @(F1.2;AGCON); 0 Lux with IR |
| frame rate | 50Hz: 25fps (2304 × 1296, 2048 × 1536, 1920 × 1080, 1080 × 720) |
| lens | 4mm, horizontal field of view: 79°; (6mm(48°); 8mm(37°); 12mm(23°) optional) |
| sensor type | 1/2.7" Progressive Scan CMOS |
| shutter | 1/3 second to 1/100,000 second |
| Day and night switching mode | ICR infrared filter type |
| Wide dynamic range | digital wide dynamic |
| BLC | Yes, selectable region |
| digital noise reduction | 3D digital noise reduction |
| video compression standard | Main stream: H.265 /H.264 |
| | Substream: H.265 /H.264/MJPEG |
| H.265 encoding type | Main Profile |
| Compressed output bit rate | 32Kbps~8Mbps |
| supporting agreement | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, |
| | PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,UDP,Bonjour |
| Interface Protocol | ONVIF(PROFILES),CGI,ISAPI |
| General function | One-key recovery, dual stream, heartbeat, mirroring, password protection, video masking, watermark technology, IP address filtering |
| Smart alarm | Cross-border detection; regional intrusion detection; motion detection; blocking alarm; network cable disconnection; IP address conflict; illegal access |
| Communication Interface | 1 RJ45 10M / 100M adaptive Ethernet port |
| Operating temperature and humidity | -30℃~60℃, humidity less than 95% (no condensation) |
| power supply | DC 12V±25% / PoE(802.3af); (model without P does not support PoE) |
| Power consumption | Non-PoE: I3: 4.5 W MAX; I5: 6.5 W MAX; I8: 10.5 W MAX |
| | PoE: I3: 5.5 W MAX; I5: 8 W MAX; I8: 12.9 W MAX |
| Protection class | IP68 |
| weight | 4kg |
| Remark | Separate DC12V Φ5.5 mm round head power supply is required |
| Infrared irradiation distance | 50m |
Features:
Smart function
Support behavior analysis: out-of-bounds detection, regional intrusion detection.
Using video compression technologies such as ROI, the compression ratio is high, the processing is very flexible, and the bit rate is ultra-low.
Image correlation
The highest resolution is up to 2304 × 1296 @ 25 fps, and real-time images can be output.
Stream smoothing settings, adapt to different requirements for image quality and fluency in different scenarios.
Support GBK font library, support more Chinese characters and uncommon characters superimposed.
Support OSD color selection.
Support corridor mode, backlight compensation, automatic electronic shutter function, adapt to different monitoring environments.
Support 3D digital noise reduction, support digital wide dynamic.
Infrared function
High-efficiency array infrared lamp, long service life, the longest irradiation distance can reach 30 (I3) meters, 50 (I5) meters, 80 (I8) meters.
Support smart IR to prevent infrared overexposure at night.
ICR outer filter type automatic switching to achieve real day and night monitoring.
Support independent configuration of two sets of parameters day and night.
System functions
Support PoE power supply function (optional).
Fully functional: heartbeat, mirroring, etc.
Support dual stream, support mobile phone monitoring.
Support EZVIZ cloud platform access.
Support Email, FTP, NTP server test.
It supports intelligent post-retrieval, and cooperates with NVR to support secondary retrieval and analysis of events.
Comply with IP68 dustproof and waterproof design, high reliability.
Security service
Supports security authentication such as HTTPS, and supports the creation of certificates.
A password must be set when the initial device is powered on to ensure password security.
Support user login locking mechanism, and password complexity prompt.
Accessories:
Explosion-proof camera wall mount BL-EX40LA
Explosion-proof camera hoisting bracket BL-EX40IA
Explosion-proof camera junction box BL-EXC200A
Explosion-proof camera hose BL-EX100P
Ordering Information:
304 stainless steel 3 million fixed focus super starlight explosion-proof network camera BL-EX336-I5
304 stainless steel 3 million Poe fixed focus super starlight explosion-proof network camera BL-EX336P-I5
316L stainless steel 3 million fixed focus super starlight explosion-proof network camera BL-EX336-I5/316L
316L stainless steel 3 million Poe fixed focus super starlight explosion-proof network camera BL-EX336P-I5/316L
