Home / Product / Special product / Mine camera / 4MP / KBA127-D7-I5(4/6/8/12mm) 4 million full color 50m infrared fixed focus network mine explosion-proof camera
Application scenarios:
The equipment has obtained the highest certification of Class II explosion-proof level and the highest certification of temperature (T) level. It is suitable for Zone 0, Zone 1, Zone 2 with IIA, IIB, IIC environment, and explosive mixtures formed by explosive and flammable gases and air in groups T1~T6. Zone 20, Zone 21, Zone 22 where explosive and flammable dust is mixed with air, such as coal mine methane gas, explosive gas, dust environment. Such as: refining, oil production, gas production, chemical industry, fireworks production, food processing and storage, gas stations and other environments.
Features:
· Product standard: GB3836-2010, MT 209-1990, Q/BL927001-2018
· Wide voltage design supports user-customized AC/DC POE power supply mode
· The window glass is precisely processed, with self-cleaning function, and can be used in a hydrofluoric acid environment
maximum image size | 2560 × 1440 |
sensor type | 1/1.8" Progressive Scan CMOS |
Minimum illumination | Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light |
lens | 4 mm, horizontal field of view: 89° [6 mm (54°) optional] |
frame rate | Main stream: 50Hz: 25fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Substream: 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288, 320 × 240) |
Day and night conversion method | day, night |
Image settings | Corridor mode, brightness, contrast, saturation, etc. can be adjusted through the client or IE browser |
Wide dynamic range | 120dB |
shutter | 1/3 s ~ 1/100,000 s |
image enhancement | Backlight compensation, 3D digital noise reduction |
video compression standard | Main stream: H.265/ H.264 |
| Substream: H.265/ H.264/ MJPEG |
H.265 encoding type | Main Profile |
H.264 encoding type | BaseLine Profile/ Main Profile/ High Profile |
Video compression bit rate | 32 Kbps ~ 8 Mbps |
supporting agreement | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, |
| PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
Interface Protocol | ONVIF(PROFILE S, PROFILE G), ISAPI, GB28181, Ehome |
General function | Heartbeat, Mirroring, Password Protection, Video Masking, Watermarking Technology, IP Address Filtering |
Storage function | NAS (NFS, SMB/CIFS are supported) |
Anomaly detection | Motion detection, occlusion alarm, illegal login, memory full, memory error |
Smart detection | Border crossing detection, area intrusion |
Communication Interface | 1 RJ45 10 M/100 M adaptive Ethernet port |
Protection class | IP67 |
power supply | Internal DC12 V ± 25% / PoE(802.3af), external AC127V |
Operating temperature and humidity | -30℃ ~ 60℃, humidity less than 95% (non-condensing) |
Power consumption | Non-PoE: 6.5 W Max |
| PoE: 8 W Max |
weight | 8kg |
The furthest fill light distance | 50m |
Main features:
1/1.8" Progressive Scan CMOS
2560 × 1440 @ 25fps
0.0005 Lux @ (F1.0,AGC ON), 0 Lux with light
H.264, Smart264, H.265, Smart265
Intelligent alarm: cross-border detection, regional intrusion detection
Backlight Compensation, 3D Digital Noise Reduction
120 dB wide dynamic
Accessories:
Mine explosion-proof camera wall mount bracket BL-EX55LA
Mine explosion-proof camera universal joint BL-EX10ZA
Mine explosion-proof camera junction box BL-EXC400A
BL-EX100P 1 meter flame retardant rubber explosion-proof hose inside and outside
Ordering Information:
4 million full color infrared 50m fixed coking coal mine underground mine explosion-proof camera KBA127-D7-I5
4 million full-color infrared 50-meter fixed-coking coal mine underground 100M fiber-optic mine explosion-proof camera KBA127-D7-I5F
