Application scenarios:
The equipment has obtained the highest certification of Class II explosion-proof level and the highest certification of temperature (T) level. It is suitable for Zone 0, Zone 1, Zone 2 with IIA, IIB, IIC environment, and explosive mixtures formed by explosive and flammable gases and air in groups T1~T6. Zone 20, Zone 21 and Zone 22 where explosive and flammable dust is mixed with air, except for coal mine methane gas, other explosive gas and dust environments. Such as: refining, oil production, gas production, chemical industry, fireworks production, food processing and storage, gas stations and other environments.
Features:
· Explosion proof mark: Exd IIC T6 Gb /ExtD A21 IP68 T80℃
· Protection class: IP68
· Product standard: Q/006-2016
· Stainless steel material design, double explosion-proof certification
· Wide voltage design supports user-customized AC/DC POE power supply mode
· The window glass is precisely processed, with self-cleaning function, and can be used in a hydrofluoric acid environment
| model | BL-EX3504H6-I8Z |
| name | 5.0MP 1/1.8"CMOS ICR Day and Night Tube Type Network Camera |
| sensor type | 1/1.8" Progressive Scan CMOS |
| shutter | 1/3 second to 1/100,000 second |
| Auto iris | DC drive |
| Day and night switching mode | ICR infrared filter type |
| Wide dynamic range | digital wide dynamic |
| BLC | Yes, selectable region |
| digital noise reduction | 3D digital noise reduction |
| slow shutter | support |
| video compression standard | H.265 / H.264 / MJPEG |
| H.265 encoding type | Main Profile |
| Compressed output bit rate | 32Kbps~16Mbps |
| Audio compression bit rate | 64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| maximum image size | 2592×1944 |
| frame rate | 50Hz: 25fps (2592 × 1944, 2560 × 1920, 2048 × 1536, |
|
| 1280 × 960, 1280 × 720) |
|
| 60Hz: 30fps (2592 × 1944, 2560 × 1920, 2048 × 1536, |
|
| 1280 × 960, 1280 × 720) |
| Resolution and frame rate of the third stream | Independent of the main stream settings, supports up to: |
|
| 50Hz: 25fps (1920 × 1080) |
|
| 60Hz: 30fps (1920 × 1080) |
| Image settings | Saturation, brightness, contrast, sharpness can be adjusted by client or browser |
| corridor mode | support |
| BLC | support, selectable area |
| Electronic image stabilization | support |
| through fog | support |
| image overlay | Support BMP 24-bit image overlay, selectable area |
| Day and night conversion method | Automatic, timing, alarm trigger |
| area of interest | ROI supports three streams to set 4 fixed areas or dynamic tracking respectively |
| Smart detection | Out-of-bounds detection, scene change detection, area intrusion detection, audio anomaly detection, virtual focus detection, motion detection, face detection, entry/exit area detection, loitering detection, crowd detection, fast Motion detection, parking detection, item left/take detection, dynamic analysis, vehicle detection, support line counting function |
| Smart Recording | Support the function of disconnecting and resuming transmission to ensure that the video is not lost, and cooperate with the Smart NVR to realize the secondary intelligent retrieval, analysis and concentrated playback of the event video |
| Smart image enhancement | Support fog penetration, Smart IR anti-infrared overexposure technology |
| Smart coding | Support low bit rate, low latency, ROI enhanced coding, SVC adaptive coding technology |
| Smart Alarm | Support network cable disconnection, IP address conflict, memory full, memory error, illegal access abnormal detection and linkage alarm function |
| Storage function | Support Micro SD/SDHC/SDXC card (128G) off-network local storage, NAS (NFS, SMB/CIFS are supported) |
| Interface Protocol | ONVIF,PSIA,CGI,ISAPI,GB28181 |
| supporting agreement | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, |
|
| PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| General function | One-key recovery, anti-flicker, three-stream, heartbeat, mirroring, password protection, video cover, watermark technology, |
|
| Anonymous access, IP address filtering |
| Communication Interface | 1 RJ45 10M/100M/1000M adaptive Ethernet port |
| Ambient noise filtering | support |
| Audio input and output | Support two-channel, stereo |
| Audio sample rate | 16kHz / 32kHz / 44.1kHz / 48kHz |
| Operating temperature and humidity | -30℃~60℃, humidity less than 95% (no condensation); |
|
| -H:-40℃~60℃ |
| power supply | DC12V 2A/ PoE(802.3at) |
| Power consumption | 14W MAX |
| Protection class | IP67 |
| weight | 6kg |
| Remark | *“-S” means it has 1 pair of 3.5mm audio input (Line in)/output interface, 1 RS-485 interface, 1 pair of alarm input/output interface (the alarm output supports DC24V 1A or AC110V 500mA at most) |
|
| *Recommended to configure two-wire power supply |
| Infrared irradiation distance | 100 meters |
Features
Main features
Smart function
· Smart detection: 10 behavior analysis, 4 abnormal detection, 2 identification detection, 1 statistical function
· Smart recording: Supports the function of disconnecting and resuming transmission to ensure that the recording is not lost, and cooperates with Smart NVR/SD card to realize intelligent post-retrieval, analysis and concentrated playback of event recordings
· Smart coding: supports low bit rate, low latency, enhanced coding of ROI region of interest, and SVC adaptive coding technology
Image correlation
· Support resolution up to 2592×1944, and support real-time output
· Support corridor mode, increase the monitoring area in the longitudinal and narrow environment
· Support area cropping, small bandwidth to see big details
· Stream smoothing settings, adapt to different requirements for image quality and fluency in different scenarios
· Support H.265 / H.264 / MJPEG video compression algorithm, support multi-level video quality configuration, encoding complexity setting
· Support GBK font library, support more Chinese characters and uncommon characters overlay, support OSD color selection
· Support fog penetration, electronic image stabilization
Infrared function
· Adopt high-efficiency infrared array lights, low power consumption, and the illumination distance is up to 100 meters
· Infrared anti-reflection panel, improve infrared light transmittance
· Smart IR function, intelligently change the brightness of the infrared light according to the focal length of the lens, so that the infrared supplementary light is uniform, the close objects are not burst, and the distant objects are not missed
System functions
· Support ONVIF (profile S/profile G), CGI, PSIA, ISAPI, GB/T28181 and EHOME protocol access
· Support three-stream technology, dual-channel high-definition, support simultaneous 20-channel streaming
· Optional intelligent temperature control, low power heating, support low temperature start (-H optional)
· Support defogging to prevent fogging inside the device
· Adopt anti-stray light glass to ensure the effect of the picture and eliminate the interference of stray light
· Support lightning protection, anti-surge, anti-static, IP67 protection level
· Support wide voltage input
Interface function
· Support standard 128G Micro SD/SDHC/SDXC card storage
· Support 10M/100M adaptive network port
· Support 1 pair of audio input/output (-S), support two-channel stereo audio
· Support 1 pair of alarm input/output (-S)
· Support BNC analog output
Security service
· Support three-level user rights management, support authorized users and passwords, support IP address filtering, support anonymous access
· Support HTTPS, SSH and other security authentication, support to create certificates
· Support user login locking mechanism
Interface function
· Support standard 128G Micro SD/SDHC/SDXC card storage
· Support 10M/100M/1000M adaptive network port
· Support 1 pair of audio input/output (-S), support two-channel stereo audio
· Support 1 pair of alarm input/output (-S)
· Support BNC analog output
security service
· Support three-level user rights management, support authorized users and passwords, support IP address filtering, support anonymous access
· Support HTTPS, SSH and other security authentication, support to create certificates
· Support user login locking mechanism
Accessories:
Explosion-proof camera wall mount BL-EX40LA
Explosion-proof camera hoisting bracket BL-EX40IA
Explosion-proof camera junction box BL-EXC200A
Explosion-proof camera hose BL-EX100P
Ordering Information:
304 stainless steel 5 million 4 times super starlight explosion-proof network camera BL-EX3504H6-I8Z (4X)
316L stainless steel 5 million 4 times super starlight explosion-proof network camera BL-EX3504H6-I8Z(4X)/316L
