Home / Product / Analog camera / Explosion-proof gimbal / BL-EX9020IBW(20x) Analog 700 line 20x zoom wiper explosion-proof PTZ camera
Application scenarios:
The equipment has obtained the highest certification of Class II explosion-proof level and the highest certification of temperature (T) level. It is suitable for Zone 0, Zone 1, Zone 2 with IIA, IIB, IIC environment, and explosive mixtures formed by explosive and flammable gases and air in groups T1~T6. Zone 20, Zone 21 and Zone 22 where explosive and flammable dust is mixed with air, except for coal mine methane gas, other explosive gas and dust environments. Such as: refining, oil production, gas production, chemical industry, fireworks production, food processing and storage, gas stations and other environments.
Features:
· Explosion proof mark: Exd IIC T6 Gb /ExtD A21 IP68 T80℃
· Protection class: IP68
· Product standard: Q/006-2016
· Stainless steel material design, double explosion-proof certification
· Wide voltage design supports user-customized AC/DC POE power supply mode
The window glass is precisely processed, with self-cleaning function, and can be used in a hydrofluoric acid environment
Image Sensor | 1/3" CMOS |
Effective Pixels | PAL: 976(H)×582(V) |
| NTSC: 976(H)×494(V) |
horizontal resolution | 720TVL |
signal system | PAL/NTSC |
Minimum illumination | 0.02Lux/(F1.6, AGC ON) (color) |
| 0.002Lux/(F1.6, AGC ON) (black and white) |
white balance | Auto / Manual / Auto Tracking White Balance / Indoor / Outdoor |
Gain control | automatic / manual |
signal to noise ratio | Greater than 50dB |
digital noise reduction | 3D Noise Reduction: High/Medium/Low/Off |
BLC | switch |
electronic shutter | PAL: 1-1/10,000s |
| NTSC: 1-1/10,000s |
Day and night mode | filter color to black |
digital zoom | 16 times |
privacy mask | Up to 8 areas, with up to 8 areas at the same time |
| on the same screen |
focus mode | Automatic / Semi-automatic / Manual |
digital wide dynamic | 128 times (on/off) |
focal length | 4.7mm-94mm, 20 times |
Zoom speed | About 3 seconds (optical, wide-angle-telephoto) |
Horizontal viewing angle | 49-2.2 degrees (Wide-Telephoto) |
close-up | 10-1500mm (wide-angle-telephoto) |
Aperture number | F1.6-F3.7 |
Horizontal range | 360° continuous rotation |
horizontal speed | Horizontal keying speed: 0.1°-250°/s, the speed can be set |
| Horizontal preset speed: 300°/s |
vertical range | Minus 90°~90° (automatic flip) |
vertical speed | Vertical keying speed: 0.1°-150°/s, the speed can be set |
| Vertical preset speed: 200°/s |
Scale zoom | support |
Number of preset points | 256 |
cruise scan | 8 strips, each can add 32 preset points |
pattern scan | 4, the recording time of each path is more than 10 minutes |
Power-off memory | support |
watch function | Preset / Pattern Scan / Cruise Scan / Horizontal Scan / Vertical Scan / Random Scan / Frame Scan / Panorama Scan |
Orientation information display | switch |
Preset video freeze | support |
timed task | Preset / Pattern Scan / Cruise Scan / Horizontal Scan / Vertical Scan / Random Scan / Frame Scan / Panorama Scan / Timing Correction |
RS-485 line fault diagnosis | support |
Mancode Support and Troubleshooting | support |
Analog video output | 1.0V[p-p] / 75Ω, PAL or NTSC, BNC connector |
RS485 control interface | Adopt half-duplex mode, support adaptive HIKVISION, PELCO-P and PELCO-D (addable) protocols |
menu | Chinese-English |
power supply | AC24V;AC220V |
| 110W max (including 8W max heating) |
Operating temperature and humidity | -30℃-65℃(outdoor) / -10℃-50℃(indoor) |
| Humidity less than 90% |
Protection class | IP66 (outdoor ball) |
| TVS 4000V lightning protection, anti-surge, anti-surge |
Installation method | A variety of installation methods can be selected according to the application environment |
weight | 25kg |
Accessories:
Explosion-proof PTZ Wall Mount Bracket BL-EX60LA
Explosion-proof camera junction box 200X150X100
Explosion-proof camera hose BL-EX100P
Ordering Information:
304 stainless steel 700 line 20 times wiper explosion-proof PTZ camera BL-EX9020IBW
316L stainless steel 700 line 20 times wiper explosion-proof PTZ camera BL-EX9020IBW/316L
