| camera |
| sensor type | 1/2.7" Progressive Scan CMOS |
| Minimum illumination | 0.002 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| shutter | 1/3 s~1/100,000 s |
| wide dynamic | 120dB |
| Day and night switching mode | ICR infrared filter type |
| lens |
| | 4 mm, horizontal field of view: 87.3°, vertical field of view: 46.3°, diagonal field of view: 104.2° |
| Focal Length & Field of View | 6 mm, horizontal field of view: 53.9°, vertical field of view: 28.8°, diagonal field of view: 62.8° |
| | 8 mm, horizontal field of view: 40.9°, vertical field of view: 22.5°, diagonal field of view: 47.4° |
| | 12 mm, horizontal field of view: 25.4°, vertical field of view: 14.4°, diagonal field of view: 29.1° |
| maximum aperture | F1.6 |
| Lens size interface | M12 |
| fill light |
| Infrared distance | up to 50 m |
| Fill light type | Infrared: 850 nm |
| video |
| maximum image size | 1920 × 1080 |
| Main stream frame rate resolution | 50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Substream frame rate resolution | 50Hz: 25fps (640×480, 640×360, 320×240) |
| video compression standard | Main stream: H.265/H.264 |
| | Substream: H.265/H.264/MJPEG |
| Video compression bit rate | 32Kbps~8Mbps |
| H.264 encoding type | BaseLine Profile/Main Profile/High Profile |
| H.265 encoding type | Main Profile |
| Smart264 encoding | support |
| Smart265 encoding | support |
| rate control | fixed rate, variable rate |
| SVC | support |
| ROI | Support main stream to set 1 fixed area |
| audio |
| Audio Ambient Noise Filtering | support |
| Audio sample rate | 16kHz |
| audio compression standard | G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM |
| Audio compression bit rate | 64 Kbps (G.711ulaw)/64 Kbps (G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726) |
| | /32~160 Kbps (MP2L2) |
| network |
| Interface Protocol (API) | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK, GB28181 |
| Network protocol | TCP/IP, ICMP, HTTP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, |
| | SMTP, IGMP, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| Network Storage | Support Micro SD/Micro SDHC/Micro SDXC card (maximum 256 GB) disconnected network local storage and disconnected network resume, |
| | NAS (NFS, SMB/CIFS are supported), with Hikvision black card to support SD card encryption and SD card status detection |
| Smart alarm | Motion detection, occlusion alarm, abnormality |
| image |
| smartIR | support |
| Day and night switching mode | Day, night, automatic, timing switch |
| image enhancement | Backlight compensation, strong light suppression, 3D digital noise reduction |
| Image settings | Saturation, Brightness, Contrast, Sharpness, AGC, White Balance adjustable through client or browser |
| interface |
| Call the police | 1 input, 1 output (alarm output supports up to DC24 V, 1 A) |
| | 1 input (Line in/Mic in) (maximum input amplitude: 3.3 Vpp, input impedance: 2.2 KΩ), 1 built-in microphone, 1 built-in speaker, 1 output (Line out) |
| audio | 1 output (Line out) |
| reset | support |
| network | 1 RJ45 10 M/100 M adaptive Ethernet port |
| smart function |
| Smart Events | Out-of-bounds detection, regional intrusion detection |
| General Specifications |
| Linkage | Upload NAS/SD card/FTP, mail, upload center, video, snapshot, sound alarm |
| General function | Anti-flicker, heartbeat, mirroring, password protection, watermark, IP address filtering, flash log, pixel counter, video |
| | frequency masking |
| reset | Support for client or browser recovery |
| Storage temperature and humidity | -30 ℃~60 ℃, humidity less than 95% (non-condensing) |
| Start-up and working temperature and humidity | -30 ℃~60 ℃, humidity less than 95% (non-condensing) |
| Power supply | DC: 12 V ± 25% Support anti-reverse polarity protection |
| current and power consumption | DC: 12 V, 1.20 A, maximum power consumption: 14.5 W |
| Power interface type | Ø5.5 mm round mouth |
| equipment weight | 5kg |
| Certification |
| Radiation level | ClassB |
| Domestic routine certification | Type inspection, GB28181 |
| protection | IP68 |
