| model | BL-EX3225W-I8Z |
| camera |
| sensor type | 1/2.8" Progressive Scan CMOS |
| scan system | line-by-line scan |
| signal system | PAL/NSTC |
| video output | network coding output |
| Resolution | 50HZ: 25fps(1920X1080) 60HZ: 30fps(1920X1080) |
| | 50HZ: 25fps(1280X720) 60HZ: 30fps(1280X720) |
| Minimum illumination | Color: 0.05Lux @ (F1.6, AGC ON) |
| | Black and white: 0.01Lux @ (F1.6, AGC ON) |
| signal to noise ratio | >52dB |
| lens |
| focal length | 4.8-120mm, 25x optical zoom |
| Aperture value | F1.6-F3.5 |
| Horizontal field of view | 57.6-2.5 degrees (Wide-Telephoto) |
| close-up | 100mm-1500mm (wide-angle-telephoto) |
| Zoom speed | About 3.6 seconds (optical, wide-angle-telephoto) |
| Day and night switching mode | ICR filter |
| parameter settings |
| focus mode | automatic/manual/semi-automatic |
| exposure mode | Auto Exposure/Aperture Priority/Shutter Priority/Manual Exposure |
| Day and night mode | Auto/color/black and white/timing/alarm input trigger |
| electronic shutter | 1/1 second ~ 1/30,000 second |
| white balance | Auto1/Auto2/Indoor/Outdoor/Manual/Incandescent/Fluorescent |
| BLC | Off/Up/Down/Left/Right/Center/Auto |
| gain | 16 levels adjustable |
| Dead pixel compensation | support |
| wide dynamic | off/on |
| Strong light suppression | switch |
| digital noise reduction | 3D |
| Lens initialization | built-in |
| Image quality adjustment | Brightness, contrast, sharpness, saturation can be adjusted |
| digital zoom | 12x |
| Network features |
| wiper | Remote on/off |
| video compression | H.265/H.264 |
| Compressed output bit rate | 32kbps-16Mbps |
| audio compression | G.722.1, G.711-a law, G.711-u law, MP2L2, G.726, AAC, PCM |
| Storage function | Support Micro SD/ Micro SDHC/Micro SDXC storage |
| Image settings | Movement functions can be adjusted through the client or IE browser |
| Smart alarm | Motion detection, occlusion alarm, memory full, memory error, audio anomaly detection, out-of-bounds detection, regional intrusion detection |
| supporting agreement | TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, FTP, 802.1x, QoS, HTTPS, IPv6 (SIP, SRTP, optional), GB28181, E-HOME |
| Interface Protocol | ONVIF, ISAPI, SDK |
| three stream | support |
| Heartbeat function | support |
| Security Mechanism | Password protection, multi-user access control |
| External Interface | Ethernet port, RS485, Alarm In/Out, Line In/Out, CVBS, |
| | Micro SD/ Micro SDHC/ Micro SDXC |
| External communication | RS485 interface, Pelco protocol |
| General Specifications |
| Communication Interface | 1 RJ45 10M/100M adaptive Ethernet port, 1 RS-485 interface |
| video output | 2 cores 1Vp-p Composite Output(75Ω) |
| audio input | 1 channel, 3.5mm audio interface (Linear level: 2.0 - 2.4Vp-p, Impedance: 1kΩ) |
| Audio output | 1 channel, 3.5mm audio interface (Linear level, Impedance: 600Ω) |
| Call the police | 1 channel alarm input, 1 channel alarm output |
| power supply | DC12V±10%, support POE |
| Operating temperature and humidity | -10℃ ~ 60℃, less than 90%RH |
| Power consumption | Static 10W, Dynamic 15W |
| weight | 7kg |
